NO. |
Item |
Technical Parameter |
Remark |
|||||
|
1 |
Number of charging interfaces |
2 |
Optional single gun |
|||||
|
2 |
Rated voltage |
380V |
|
|||||
|
3 |
Rated frequency |
50Hz |
|
|||||
|
4 |
Input voltage |
380V±15% |
|
|||||
|
5 |
Output voltage |
200V-750V |
|
|||||
|
6 |
Rated output current |
53A |
80A |
120A |
160A |
200A |
200A |
|
|
7 |
Output maximum power |
40KW |
60KW |
80KW |
120KW |
160KW |
240KW |
|
|
8 |
CI |
4G wireless networking, wired networking |
Option |
|||||
|
9 |
Communicating protocol |
Cloud fast charge V1.5/OCCP1.6 |
Option |
|||||
|
10 |
Input mode |
touch |
|
|||||
|
11 |
Starting mode |
Private card system / commercial credit card payment |
|
|||||
|
12 |
Display screen |
7inch color industrial-grade display screen |
|
|||||
|
13 |
Monitoring platform |
Integrated card issuing, operation, monitoring and maintenance in one |
|
|||||
|
14 |
Dielectric strength |
≥2000V |
|
|||||
|
15 |
Leakage current |
≤3.5mA |
|
|||||
|
16 |
Levels of protection |
IP54 |
|
|||||
|
17 |
Work environment |
-20~50℃ |
|
|||||
|
18 |
Working humidity |
5%-95% |
|
|||||
|
19 |
Interface type |
CCS1, CCS2, GBT |
|
|||||
|
20 |
Measurement function |
Electricity meter measurement |
|
|||||
|
21 |
Protocol standard |
ISO15118/DIN70121 |
|
|||||
|
21 |
Cooling-down method |
air blast cooling |
|
|||||
|
22 |
Defensive function |
Overvoltage short circuit protection, overload protection, leakage protection, surge protection reverse protection, over temperature protection, output over under voltage protection, etc. |
|
|||||
|
23 |
Way to install |
integrated |
|
|||||
|
24 |
power factor |
0.99 |
|
|||||
|
25 |
overall efficiency |
94% |
|
|||||
