Item times

project

technical parameter

remarks

1

Number of charging interfaces

2

Optional single gun

2

rated voltage

380V

3

rated frequency

50Hz

4

input voltage

380V±15%

5

output voltage

200V-750V

6

rated output current

53A/80A/120A/160A/200A/200A

7

Output maximum power

40KW/60KW/80KW/120KW/160KW/240KW

8

CI

4G wireless network, wired network

apolegamy

9

communicating protocol

Cloud fast charge V1.5/OCCP1.6

apolegamy

10

Interface type

CCS 1/CCS 2/CHAdeMO/GB/T

11

input mode

Touch Screen

12

starting mode

Private card system / commercial credit card payment

Optional credit card, scan the code

13

display screen

7inch color industrial-grade display screen

14

Monitoring platform

Integrated card issuing, operation, monitoring and maintenance in one

15

dielectric strength

≥2000V

16

leakage current

≤3.5mA

17

IP Grade

IP54

18

work environment

-20~50℃

19

Working humidity

5%-95%

20

Interface type

European standard CCS2

210

Measurement function

Electricity meter measurement

22

protocol standard

ISO15118/DIN70121

23

cooling-down method

air blast cooling

24

defencive function

Overvoltage short circuit protection, overload protection, leakage protection, surge protection reverse protection, over temperature protection, output over undervoltage protection, etc.

25

way to install

integrated

26

power factor

0.99

27

overall efficiency

94%
